CONSTANT HV 18 High Voltage 1000 V Electric Tool Set - 18 Pcs (Include Check Pen Pro)


Specifications CONSTANT Check Pen Pro 1000V

FunctionRange
IndicatorsLED and Tone
Voltage50 ~ 1000VAC
Frequency50 ~ 500Hz
Battery2 x 1.5V (AAA size)
Standard AccessoriesBattery, Manual


Keterangan:
1. READY STOCK
2. SAME DAY DELIVERY
3. JAMINAN GARANSI LANGSUNG


PT. Graphic Control
Jl. Mulyosari Tengah I No 10, SURABAYA
Telp. : 031 593 6888
Fax. : 031 593 4442
HP.: 085706168917, 082332862674

CONSTANT MT 136 Profesional Maintenance Tool Set - 136 Pcs (Include DMM 90F)


Specifications CONSTANT Digital Multimeter 90F Auto Range

FUNCTIONRANGEACCURACY
AC Current400µ/4m/40m/400m/4/10A±(1.5% rdg ± 3dgt)
AC Voltage400mV±(3.0% rdg + 3 dgt)
4/40/400/1000V±(1.0% rdg + 3 dgt)
DC Current400µ/4m/40m/400m/4/10A±(1.5% rdg + 3 dgt)
DC Voltage400mV±(1.0% rdg ± 10 dgt)
4/40/400/1000V±(0.5% rdg + 3 dgt)
Input Impedance>5MΩ (ACV) and >10MΩ (DCV)
Resistance400.0Ω±(0.5% rdg + 3 dgt)
4.00k/40.0k/400.0k/4.000MΩ±(0.5% rdg + 2 dgt)
40.00MΩ±(1.5% rdg + 3 dgt)
Capacitance50nF (<10nF)±(5.0%[rdg-50dgt] +10 dgt)
50nF (≥10nF)±(3.0% rdg + 10 dgt)
500n/5µ/50µ/100µF±(3.0% rdg + 5 dgt)
Frequency50.00/500.0/5.000k/50k/100kHz±(0.1% rdg + 3 dgt)
Temperature-55 ~ 0°C±(9.0% rdg + 2°C)
1 ~ 400°C±(2.0% rdg + 1°C)
401 ~ 1000°C±2.0% rdg
Diode TestDisplay forward voltage drop of the diode
ContinuityIf continuity exists (≤ 75Ω), built in buzzer will sound
Display3¾ digits
IndicationLow battery, over range, negative polarity
Battery / Fuse3 x 1.5V (AAA size)
Size / Weight185 x 87 x 53mm / ±360g (including battery)
Standard AccessoriesTest Leads, batteries, K type thermocouple, instruction manual
warranty card, certificate of product conformance

Keterangan:
1. READY STOCK
2. SAME DAY DELIVERY
3. JAMINAN GARANSI LANGSUNG


PT. Graphic Control
Jl. Mulyosari Tengah I No 10, SURABAYA
Telp. : 031 593 6888
Fax. : 031 593 4442
HP.: 085706168917, 082332862674

CONSTANT Calibrator Loop20


OuputMeasuring RangeOutput RangeResolutionAccuracyRemark
Current20mA0.000~22.0000.001mA±0.05% of setMax. 1KΩ at 20mA
value or ±4µA(see manual for detail)
Simulation-20mA0.000~22.0000.001mA±0.05% of setMax. 1KΩ at 20mA
of Transmittervalue or ±4µA(see manual for detail)
Loop power24V--±4%Max. output current up to 25mA
InputRangeInput RangeResolutionAccuracyRemark
Voltage28V-0.200 ~ 28.000V1mV±0.02% of readingInput resistance 2MΩ
or ±2mV
Current20mA-1.000 ~ 22.000mA0.001mA±0.02% of readingInput resistance 10Ω
or ±4µA
Loop20mA0.000 ~ 22.000mA0.001mA±0.02% of readingProviding 24V loop
Currentor ±4µApower


Keterangan:
1. READY STOCK
2. SAME DAY DELIVERY
3. JAMINAN GARANSI LANGSUNG


PT. Graphic Control
Jl. Mulyosari Tengah I No 10, SURABAYA
Telp. : 031 593 6888
Fax. : 031 593 4442
HP.: 085706168917, 082332862674

CONSTANT HT100 Thermohygro Meter (Humidity Meter ) With Clock)



 Fungsi : Alat Untuk Mengukur Suhu Ruangan

Temperature Range-50° ~ 70°C (-58° ~ 158°F)
Humidity Range20% ~ 99% RH
Temperature Resolution0.1°C (0.1°F)
Humidity Resolution1% RH
Temperature Accuracy1°C (1.8°F)
Humidity Accuracy5% RH
Power1 x 1.5V (AAA)
SizeH100 x W108 x D20mm
WeightApprox. 160g
Storage Temperature-20° ~ 60°C
Storage Humidity20% ~ 80% RH

Keterangan:
1. READY STOCK
2. SAME DAY DELIVERY
3. JAMINAN GARANSI LANGSUNG


PT. Graphic Control
Jl. Mulyosari Tengah I No 10, SURABAYA
Telp. : 031 593 6888
Fax. : 031 593 4442
HP.: 085706168917, 082332862674

CONSTANT PH 47 (PH Meter)


Alat Pengukur Asam Basah

Range0 ~ 14.0pH
Accuracy±0.1 + 1 digit
Resolution0.1pH
Power2 x 3V CR2032 lithium battery
Size33.5 x 170mm
Weight±85g (including batteries)
Accessoriesbuffer pH 4 & pH 7, soaking solution, batteries, instruction manual,
warranty card, certificate of product conformance


Keterangan:
1. READY STOCK
2. SAME DAY DELIVERY
3. JAMINAN GARANSI LANGSUNG


PT. Graphic Control
Jl. Mulyosari Tengah I No 10, SURABAYA
Telp. : 031 593 6888
Fax. : 031 593 4442
HP.: 085706168917, 082332862674

CONSTANT Tachometer RPM 78


Fungsi : Alat untuk mengukur kecepatan Rotasi / Kecepatan putaran dari Poros
Measurement RangeNon-Contact Tachometer :
5 ~ 99999RPM
Contact Tachometer :
0.5 ~ 19999RPM
Surface Speed :
0.05 ~ 1999.9m/min.
0.2 ~ 6560ft/min
ResolutionRPM :
0.1 RPM (< 1000rpm)
1 RPM (≥ 1000rpm)
Surface speed :
0.01m/min (< 100m/min.)
0.1m/min (≥ 100m/min.)
0.1ft/min (< 1000ft/min)
1ft/min (≥ 1000ft/min)
DisplayLCD, size 60x30mm
5 digits with display unit
Accuracy±(0.05%  + 1 digit)
Detecting Distance5 ~ 100cm typically
LaserLess than 1mW, class 2 laser diode, red wave length is 645nm approximately
Operating Temperature0 ~ 50°C (32 ~ 122°F)
Operating Humidity< 80% RH
MemoryLast/maximum/minimum value
Battery4 x 1.5V (AA size)
Size215 x 75 x 38mm
Standard AccessoriesBatteries, reflecting tape marks (600mm), RPM adapter (cone, funnel, surface speed test wheel), instrcution manual, warranty card, certificate of product conformance

Keterangan:
1. READY STOCK
2. SAME DAY DELIVERY
3. JAMINAN GARANSI LANGSUNG


PT. Graphic Control
Jl. Mulyosari Tengah I No 10, SURABAYA
Telp. : 031 593 6888
Fax. : 031 593 4442
HP.: 085706168917, 082332862674

CONSTANT Light / Lux Meter LG40


Fungsi : Untuk mengukur Intensitas Cahaya
Measurement Range200, 2000, 20000, 40000 lux/fc (1fc = 10.76lux)
Accuracy±5% rdg ± 10dgts (<10000 lux/fc)
±10% rdg ± 10 dgts (>10000 lux/fc)
Repeatability±2%
Measurement rate2.5 times per second, nominal
Temp. Characteristics±0.1%/°C
Photo detectorone silicon photo diode with filter
Display1999 counts
Indicationpolarity, over range, low battery
Storage temperature-10 ~ 60°C (14 ~ 140°F) at 80% RH
Operating temperature0 ~ 40°C (32 ~ 104°F)
Operating humidity0 ~ 80% RH
Auto power off±17 minutes
Power9V battery
Size157 x 54 x34mm
Weight±170g
Accessoriesbattery, instruction manual, warranty card,
certificate of product conformance

Keterangan:
1. READY STOCK
2. SAME DAY DELIVERY
3. JAMINAN GARANSI LANGSUNG


PT. Graphic Control
Jl. Mulyosari Tengah I No 10, SURABAYA
Telp. : 031 593 6888
Fax. : 031 593 4442
HP.: 085706168917, 082332862674

CONSTANT TDS 19 (TDS / TOTAL DISOLVIDE SOLID Pen Tester)



Fungsi : Untuk Mengetahui Total Disolvide Solid dalam Air ( Total zat padat yang terlarut dalam air )
Range0 ~ 1990ppm
Accuracy±1%FS
Resolution10ppm
Power2 x 3V CR2032 lithium battery
Size33.5 x 170mm
Weight±85g (including batteries)
Accessoriesstandard solution 940ppm, batteries, instruction manual,
warranty card, certificate of product conformance

Keterangan:
1. READY STOCK
2. SAME DAY DELIVERY
3. JAMINAN GARANSI LANGSUNG


PT. Graphic Control
Jl. Mulyosari Tengah I No 10, SURABAYA
Telp. : 031 593 6888
Fax. : 031 593 4442
HP.: 085706168917, 082332862674

CONSTANT DC 600 Vibration Meter With 99 Memories


Fungsi : Alat Untuk mengukur getaran
FunctionRangeAccuracy
SensorPiezo-Elecrical acceleration type
Acceleration0.1 ~ 19.99m/s2 (Peak)±(5% rdg + 1 dgt)
Velocity0.01 ~ 199.9mm/s (RMS)±(5% rdg + 1 dgt)
Displacement0.01 ~ 1.999mm (Peak to Peak)±(5% rdg + 1 dgt)
Frequency RangeAccelerationLo mode10Hz ~ 1kHz
Hi mode1kHz ~ 5kHz
Velocity10Hz ~ 1kHz
Displacement10Hz ~ 1kHz
Operating Temperature0° ~ 50°C
Humidity30% ~ 80%
Display3½ digits, 1999 counts
Memory Address00 - 99 (100 readings)
Battery2 x 1.5V (AAA size)
Size / WeightH147.5 x W32 x D25.8mm / Approx. 70g
Standard AccessoriesVibration Trending Analysis Software VER. 0.1, RS232 Cable,
Carrying Case, Battery, Manual, Constant Certificate
